MODELZD6000SESpecification● AC frequency: 50HZ● MIGBT+3 Phase rectifying bridge(PWM)● AC voltage : 220V● Cont.AC.output : 4.5KW● Max AC.output : 5.0KW●Welding voltage No-load DC(v) : 63-85●Welding ope
| MODEL | ZD6000SE |
| Specification | ● AC frequency: 50HZ |
| ● MIGBT+3 Phase rectifying bridge(PWM) | |
| ● AC voltage : 220V | |
| ● Cont.AC.output : 4.5KW | |
| ● Max AC.output : 5.0KW | |
| ●Welding voltage No-load DC(v) : 63-85 | |
| ●Welding operating Voltage(V) : 20-30 | |
| ●Rated welding current DC(A) : 180 | |
| ●Welding current adjustment rang DC(A) 50-180 | |
| ●Welding load cotinuous ratio 60% | |
| ● Engine model : JD186FA | |
| ● Type of engine : Air cooled,4-stroke | |
| ● Starting system : Electric start &32A battery | |
| ● Fuel tank capacity : 12.5L |
